Daikin FH35BZV1 [7/26] Specifications
![Daikin FH35BZV1 [7/26] Specifications](/views2/1779625/page7/bg7.png)
ELECTRICAL SPECIFICATIONS
For indoor units only: FH35BZV1 FH45BZV1 FH60BZV1
CURRENT Nominal running
current
cooling
A---
For combination indoor units + outdoor units: FH35BZV1 FH45BZV1 FH60BZV1
R35GZ7V11 R45GZ7V11/W11 R60GZ7W1
CURRENT Nominal running
current
cooling
A 6.4 10.8/3.98 5.6/6.35
Maximum running
current
cooling
A - - 6.8/7.7
Starting current
cooling
A 33.5 48/19 26
For indoor units only: FH35BZV1 FH45BZV1 FH60BZV1
POWER SUPPLY V1 V1 V1
NOMINAL
DISTRIBUTION
SYSTEM VOLTAGE
Phase 1∼ 1∼ 1∼
Frequency Hz 50 50 50
Voltage V 220-240 220-240 220-240
ELECTRICAL SPECIFICATIONS
For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1
CURRENT Nominal running current A - - -
For combination indoor units + outdoor units: FHYP71BV1 FHYP100BV1 FHYP125BV1
RP71B7V1/W1/T1 RP100B7V1/W1/T1 RP125B7W1/T1
CURRENT Nominal running
current
cooling
A---
Maximum running current A - - -
For indoor units only: FHYP71BV1 FHYP100BV1 FHYP125BV1
POWER SUPPLY V1 V1 V1
NOMINAL
DISTRIBUTION
SYSTEM VOLTAGE
Phase 1∼ 1∼ 1∼
Frequency Hz 50 50 50
Voltage V 220-240 220-240 220-240
NOTES
1 Nominal cooling capacities are based on: indoor temperature: 27°CDB/19°CWB * outdoor temperature: 35°CDB/24° CWB * refrigerant
piping length: 7.5m * level difference 0m.
2 Capacities are net, including a deduction for cooling for indoor fan motor heat.
3 The sound pressure level is measured in an anechoic room at 1m distance from the unit. It is a relative value, depending on the distance
and acoustic environment. For measuring conditions: please refer to item 6 of this chapter.
4 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.
• Ceiling Suspended Unit • R-407C • FH(Y)-GZ/BZ/FHYP-B
2
Specifications
10
2
5
• Split - Sky Air • Indoor Units
