Daikin FH35BZV1 [5/26] Specifications
![Daikin FH35BZV1 [5/26] Specifications](/views2/1779625/page5/bg5.png)
2
Specifications
NOMINAL CAPACITY and NOMINAL INPUT
For indoor units only:
INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1
NOMINAL INPUT Cooling kW 0.111 0.111 0.115
For combination indoor units + outdoor units:
INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1
OUTDOOR UNITS R35GZ7V11 R45GZ7V11/W11 R60GZ7W1
NOMINAL CAPACITY
(2)
Cooling (1) kW 3.75 5.20/5.20 6.50
NOMINAL INPUT Cooling kW 1.50 2.15/2.05 2.67
TECHNICAL SPECIFICATIONS
For indoor units only:
INDOOR UNITS FH35BZV1 FH45BZV1 FH60BZV1
DIMENSIONS Unit H mm 195 195 195
W mm 960 960 1,160
D mm 680 680 680
WEIGHT Unit kg 23 24 26
MATERIAL Unit - - -
COLOUR Unit White
SOUND LEVEL Sound pressure (3) high dB(A) 37 38 38
low dB(A) 32 33 33
Sound power (4) high dB(A) 53 54 54
low dB(A) 48 49 49
FAN Air flow rate
(cooling)
high m
3
/min 13 13 16
medium
m
3
/min - - -
low m
3
/min 10 10 13
Speed steps 2 steps 2 steps 2 steps
high rpm - - -
low rpm - - -
Type Sirocco fan
Qty x model 1 x 3D12K1AA1 1 x 3D12K1AA1 1 x 4D12K1AA1
Qty x motor output W 1 x 62 1 x 62 1 x 62
HEAT EXCHANGER Type Cross fin coil (Multi louver fins and N-HiX tubes)
Rows x stages x fin pitch mm 2 x 12 x 1.75 3 x 12 x 1.75 3 x 12 x 1.75
Face area m
2
0.182 0.182 0.233
AIR FILTER - - -
AIR DIRECTION CONTROL - - -
TEMPERATURE CONTROL - - -
PIPING CONNECTIONS liquid mm φ6.4 (flare) φ6.4 (flare) φ6.4 (flare)
gas mm φ12.7 (flare) φ15.9 (flare) φ15.9 (flare)
drain
mm VP20 (I.D. φ20) VP20 (I.D. φ20) VP20 (I.D. φ20)
drain
mm VP20 (O.D. φ26) VP20 (O.D. φ26) VP20 (O.D. φ26)
INSULATION
MATERIAL
Heat insulation Foamed polystyrene / Foamed polyethylene
Sound absorbing insulation Foamed polyurethane/Glass wool
For outdoor units
only:
Pair application See chapter R-GZ7/RP-B7
Multi model application See chapter MA-GZ7
• Ceiling Suspended Unit • R-407C • FH(Y)-GZ/BZ/FHYP-B
10
2
3
• Split - Sky Air • Indoor Units
