24
5 RMX140JZVMB
Super Multi Plus, Inverter controlled - heat pump
BACKGROUND
After the successful introduction of the RMX140JVMB, Daikin has now launched its RMX140JZVMB
with R-407C refrigerant.
MODEL RANGE
OUTDOOR UNIT
Heat pump
MODEL NAME
RMX140JZVMB
CONNECTABLE INDOOR UNITS
25 class FTX25JAV1NB FTXD25KZV1B FVX25KZV1B FLX25HV1NB CDX25HAV1NB - -
35 class FTX35JAV1NB FTXD35KZV1B FVX35KZV1B FLX35HV1NB CDX35HAV1NB FHYB35FK7V1 FHYC35B7V1
45 class - - - - - FHYB45FK7V1 FHYC45B7V1
50 class FTXD50JAV1NB - - FLX50JV1 CDX50HAV1NB - -
60 class FTXD60JAV1NB - - FLX60JV1 CDX60HAV1NB FHYB60FK7V1 FHYC60B7V1
71 class FTXD71JAV1NB - - - - FHYB71FK7V1 FHYC71B7V1
Branch provider
Refnet
IT IS POSSIBLE TO CONNECT UP TO 7
INDOOR UNITS TO A SINGLE OUTDOOR UNIT
R-407C logo
toevoegen
RMX140JZVMB
R-407C logo
toevoegen
