59
MEASURING CONDITIONS
COOLING ONLY
1) nominal cooling capacities are based on:
indoor temperature 27°CDB/19°CWB
outdoor temperature 35°CDB
refrigerant piping length 7.5m - 8/5m VRV
level difference 0m
HEAT PUMP
1) nominal cooling capacities are based on:
indoor temperature 27°CDB/19°CWB
outdoor temperature 35°CDB
refrigerant piping length 7.5m - 8/5m VRV
level difference 0m
2) nominal heating capacities are based on:
indoor temperature 20°CDB
outdoor temperature 7°CDB/6°CWB
refrigerant piping length 7.5m - 8/5m VRV
level difference 0m
The sound pressure level is measured via a microphone at a certain distance from the unit. It is a relative value, depending on the distance and acoustic
environment (for measuring conditions: please refer to the technical databooks).
The sound power level is an absolute value indicating the “power” which a sound source generates.
For more detailed information please consult our technical databooks.
T1 = 3~, 220V, 50Hz
V1 = 1~, 230V, 50Hz
VE = 1~, 230V, 50Hz
POWER SUPPLY
W1 = 3N~, 400V, 50Hz
Y1 = 3~, 400V, 50Hz
HYDRONIC SYSTEMS
Air-cooled chillers Evaporator: 12°C/7°C ; ambient: 35°C
Water-cooled chillers Evaporator: 12°C/7°C
Condenser: 30°C/35°C
Fan coil units cooling Entering air temperature: 27°CDB / 19°CWB
Entering water temperature: 7°C
Water temperature rise: 5K
heating Entering air temperature: 20°C
Entering water temperature: 70°C (FWV/FWH/FWM); 80°C (FWD)
Water temperature decrease: 10K
00225•New products•01-12 09-11-2001 11:18 Pagina 60
