SPECIFICATIONS
EUWA*40MZ EUWA*50MZ EUWA*60MZ EUWA*80MZ EUWA*100MZ
111 144 164 203 274
43 53 65 80 103
100-74-48-0
Semi - hermetic single screw compressor
R-407C
1/1 1/1 1/1 1/1 1/1
2,250x2,340x2,238 2,250x4,280x2,238
1,346 1,610 1,637 2,833 2,565
1,354 1,623 1,653 2,853 2,592
91 94 95 98 98
3~, 50Hz, 400V
Nominal cooling capacity kW
Nominal power input kW
Capacity steps %
Compressor type
Refrigerant type
No. of circuits/compressors
Dimensions HxWxD mm
Machine weight kg
Operation weight kg
Sound power level dBA
Power supply Y1
option option description model-type unit size
availability
number PED d s 40 50 60 80 100 120 160 180 200
Completely combinable options
op03 dual pressure relief valve on the condenser o std std o o o o o o o o o fact. mounted
op12 suction stop valve o std std o o o o o o o o o fact. mounted
op52 main isolator switch (only y1-model) o o o o o o o o o o o o fact. mounted
op57 a-meter, V-meter o o o o o o o o o o o o fact. mounted
OPLN low noise operation o o o o o o o o o o o o fact. mounted
OPCG condenser protection grilles o o o o o o o o o o o o fact. mounted
o available
std standard
OPTIONS
EUWA*120MZ EUWA*140MZ EUWA*160MZ EUWA*180MZ EUWA*200MZ
313 392 419 479 539
130 150 158 190 213
100-74-48-0 100-74-48-36-0
100-87-74-61-48-24-0 100-89-74-63-48-27-0 100-87-74-61-48-24-0
(100% compressor leads)
Semi - hermetic single screw compressor
R-407C
1/1 1/1 2/2 2/2 2/2
2,250x4,280x2,238 2,250x5,906x2,238
3,404 4,500 5,002 5,044 5,086
3,438 4,574 5,076 5,125 5,174
99 100 100 101 102
3~, 50Hz, 400V
Nominal cooling capacity kW
Nominal power input kW
Capacity steps %
Compressor type
Refrigerant type
No. of circuits/compressors
Dimensions HxWxD mm
Machine weight kg
Operation weight kg
Sound power level dBA
Power supply Y1
