CONTROL SYSTEMS
FXYAP-LVE
Wired remote control
Infrared remote control Cooling only
Heat pump
Centralised remote control
Unified on/off control
Schedule timer
Wiring adapter
Wiring adapter for electrical appendices (1)
Wiring adapter for electrical appendices (2)
External control adapter for outdoor unit
Mix matching adapter for « K » indoor unit
Remote sensor
Electrical box with earth terminal (2 blocks)
Electrical box with earth terminal (3 blocks)
Noise filter (for electromagnetic interface use only)
20 25 32
BRC1C517
BRC7C511W
BRC7C510W
DCS302B51
DCS301B51
DST301B51
KRP1B3
KRP2A51
KRP4A51
DTA104B61
DTA106A61
KRCS01-1
KJB212A
KJB311A
KEK26-1
ACCESSORIES
20 25 32
K-KDU572BVE
FXYAP-LVE
Drain pump kit
00225•New products•01-12 09-11-2001 11:17 Pagina 35
