33
8 FXYAP20-32LVE
Wall mounted unit
BACKGROUND
The current range of wall mounted units, FXYAP20,25,32KV19 will be replaced by the new L series.
The new wall mounted units are compact and suitable for commercial and residential applications.
MODEL RANGE
FXYAP20-32LVE
FEATURES
• new & compact casing :
- reduction in width from 1,050 to 795 mm
- reduction in height from 360 to 290 mm
• dramatic weight reduction : from 21 to 11 kg
INDOOR UNIT
FXYAP20LVE
FXYAP25LVE
FXYAP32LVE
*Model name is not yet fixed
SPECIFICATIONS
FXYAP-LVE
Cooling capacity kW
Heating capacity kW
Dimensions HxWxD mm
Weight kg
Colour
Air flow rate H/L m
3
/min
Sound pressure level H/L dBA
20 25 32
2.0 2.5 3.15
2.2 2.8 3.4
290x230x795
11
white (B-272)
7.5/4.5 8.0/5.0 9.0/5.5
35/29 36/29 37/29
