SiENBE28-901 Standard Specification
Air Cooled Refrigeration Condensing Unit 13
2.2 Set Values for Functional Components and Protection
Devices
Component Electric symbol
LRMEQ5AY1,6AY1
LRLEQ5AY1,6AY1
LRMEQ8AY1,10AY1,12AY1
LRLEQ8AY1,10AY1,12AY1
LRMEQ15AY1,20AY1
LRLEQ15AY1,20AY1
Compressor
Inverter
Type
M1C
JT1GFDKTNYR@SB
Overcurrent protection device 14.7A
STD1
Type
M2C
— JT17GFKTNYE@SB
Overcurrent protection device — 13A
STD2
Type
M3C
— — JT17GFKTNYE@SB
Overcurrent protection device — — 13A
Fan motor
Output
M1F
350W 750W
Overcurrent protection device 1.5A 3.0A
Output
M2F
— — 750W
Overcurrent protection device — — 3.0A
PCB
Main PCB A1P Standard:EB09058
PCB for compressor INV A3P Standard:PC0509-2
PCB for fan INV
A4P PC0511-3(A) PC0511-1(A)
A8P — — PC0511-2(A)
PCB for operation input A5P EB0568(A)
PCB for noise filter A2P FN354-H-1(A)
PCB for current sensor
A6P — EB0292(C)
A7P — — EB0292(C)
PCB for earth leakage detection A9P EC0726(A)-9 EC0729(A)-29
Electronic expansion valve
Coil
Y1E
(Main)
UKV-A023 UKV-A023 UKV-A024
DC12V, 0.26A DC12V, 0.26A DC12V, 0.26A
Body
UKV-32D49
0~480pls
Coil
Y2E
(Gas)
UKV-A023 UKV-A023 UKV-A024
DC12V, 0.26A DC12V, 0.26A DC12V, 0.26A
Body
UKV-18D20
0~480pls
Coil
Y3E
(M1C)
— UKV-A023 UKV-A024
— DC12V, 0.26A DC12V, 0.26A
Body
— UKV-32D49
— 0~480pls
Four way valve
Coil
Y3S
STF-G01AQ531A1 STF-G01AQ532A1 STF-G01AQ537A1
Body STF-0404G STF-0713G STF2011G
Solenoid valve
Coil
Y2S
(M2C)
— NEV-MOAJ562D1 NEV-MOAJ562D1
Body — VPV-603D VPV-603D
Coil
Y5S
(M3C)
— — NEV-MOAJ562C1
Body — — VPV-603D
Pressure protection device
High pressure
switch
Type
S1PH
ACB-1TB29W ACB-1TB28W ACB-1TB27W
Set value OFF 3.8 MPa ON 2.85±0.15MPa
Type
S2PH
— ACB-1TB27W ACB-1TB27W
Set value — OFF 3.8 MPa ON 2.85±0.15MPa
Type
S3PH
— — ACB-1TB27W
Set value — —
OFF 3.8 MPa
ON 2.85±0.15MPa
Type
S4PH
ACB-JB285
Set value DC5V ON: 2.96 MPa OFF: 2.16±0.15MPa
Low pressure sensor S1NPL 150NH4-L2 200NH4-L2 200NH4-L2
High pressure sensor S1NPH 150NH4-H4 150NH4-H4 200NH4-H4
Fusible plug — Open: 70~75°C
Thermistor
Outdoor air thermistor R1T ST8603
Suction pipe thermistor R2T ST0602
Outdoor heat exchanger outlet
thermistor
R3T ST8602A
Subcooling heat exchanger outlet
thermistor
R5T ST0601
Subcooling heat exchanger inlet
thermistor
R6T ST0601
Discharge pipe thermistor
R31T ST0901
R32T — ST0901
R33T — — ST0901
Fuse (A1P) F1U, F2U 250VAC 3.15A, Class T
Fuse F3U, F4U 250VAC 1.0A, Class T
Operation switch S1S AR22PR-311B Z9
+0
-0.1
+0
-0.1
+0
-0.1
+0
-0.1
