SiENBE28-901 Troubleshooting
Air Cooled Refrigeration Condensing Unit 85
Troubleshooting
Note: ∗1 One of the possible factors may be chattering due to rough MgS contact.
∗2 Abnormal case
The current sensor value is 0 during STD compressor operation.
The current sensor value is more than 14.95A during STD compressor stop.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Is the stop valve open?
Obstacle exists
around the air
outlet.
Is the power
supply voltage
normal?
Is the magnetic switch
(K2M, K3M) normal?
(
∗
1)
Check the wiring from power supply ~ current sensor (A6P, A7P) ~
MgS (K2M, K3M) ~ compressor
Is above wiring
correct?
Is current sensor
correct? ∗1
NO
YES
YES
NO
NO
YES
NO
YES
NO
YES
NO
YES
Open the stop valve.
Remove the obstacle.
Correct the power voltage.
Replace the magnetic
switch.
Correct wiring.
Replace the corresponding
current sensor
(A6P or A7P).
Retry
Replace the outdoor unit
PCB (A1P).
Replace the compressor.
