Introduction SiENBE28-901
6 Air Cooled Refrigeration Condensing Unit
Air Cooled Refrigeration Condensing Unit
Nomenclature
Outdoor unit
LR
M
EQ5 A
Y1
Power supply symbol
Y1: 3φ 380-415V, 50Hz
Indicates major design category
Capacity indication
5: 5HP
Refrigerant
Q: R-410A
Compressor type
E: Intermediate INJ type
Temperature zone to be used
M: Medium temperature (MT)
L: Low temperature (LT)
Product category
L: Low temperature air conditioner
R: Outdoor unit
