SiENBE28-901 Troubleshooting
Air Cooled Refrigeration Condensing Unit 79
6.4 Checking Malfunction Codes of the Condensing Unit
Operate the pushbuttons on the PCB and malfunction codes will be displayed by LEDs.
Setting Modes: 1-14, 15, 16, 20, 21, 22
[Steps]
1. Make sure that the "H1P" LED is OFF.
(If the LED is ON, press the MODE button (BS1) once.)
2. Press the MODE button (BS1) once to enter the "monitor mode".
3. Pressing the RETURN button (BS3) will display the first digit of a malfunction code by LED.
4. Pressing the SET button (BS2) will display the second digit of the malfunction code by LED.
5. Pressing the MODE button (BS1) will go back to the former state.
BS1
MODE
BS2
SET
BS3
RETURN
BS4
TEST
BS5
RESET
LED display
Remote
controller
display
Malfunction contents
Page
referred
(Pressing the BS3 switch once) (Pressing the BS2 switch once)
H1P H2P H3P H4P H5P H6P H7P H1P H2P H3P H4P H5P H6P H7P
lhkhhlllkh
hhhh
E0
STD Compressor Motor Overcurrent/
Lock
P.84
hhlh
E2 Earth Leakage P.86
hhll
E3 Actuation of High Pressure Switch P.88
hlhh
E4 Actuation of Low Pressure Sensor P.90
hlhl
E5 Inverter Compressor Motor Lock P.92
hlll
E7 Malfunction of Outdoor Unit Fan Motor P.94
lhhl
E9
Malfunction of Electronic Expansion
Valve Coil
P.97
lhkhlhllkhhhll
F3 Abnormal Discharge Pipe Temperature P.99
lhkhlhhlkh
hhhh
H0 Three-sensor Malfunction P.101
hhll
H3
Malfunction Related to High Pressure
Switch
P.103
hlll
H7 Abnormal Outdoor Fan Motor Signal P.104
lhhl
H9 Malfunction of Outdoor Air Thermistor P.106
lhkhllhlkh
hhlh
J2 Current Sensor Malfunction P.107
hhll
J3
Malfunction of Discharge Pipe
Thermistor
P.108
hlhl
J5 Malfunction of Suction Pipe Thermistor P.108
lhhh
J8
Malfunction of Heat Exchanger
Intermediate Inlet Thermistor
P.108
lhhl
J9
Malfunction of Heat Exchanger
Intermediate Outlet Thermistor
P.108
lhlh
JA Malfunction of High Pressure Sensor P.110
llhh
JC Malfunction of Low Pressure Sensor P.112
lhkhllllkh
hhhl
L1 Faulty Inverter PCB P.114
hlhh
L4
Malfunction of Inverter Radiating Fin
Temperature Rise
P.115
hlhl
L5
INV Compressor Instantaneous
Overcurrent
P.116
lhhh
L8 INV Compressor Overload P.118
lhhl
L9 Faulty INV Compressor Startup P.120
llhh
LC
Malfunction of Transmission (between
Inverter PCB and Main PCB)
P.122
lhklhhhlkh
hhhl
P1 Power Supply Voltage Imbalance P.124
hlhh
P4 Faulty Radiation Fin Thermistor P.125
lhklhhhlkhllhl
PJ Faulty of Capacity Setting —
lhklhhllkh
hhhl
U1 Reverse Phase / Open Phase P.126
hhlh
U2 Abnormal Power Supply Voltage P.127
