SiENBE28-901 Troubleshooting
Air Cooled Refrigeration Condensing Unit 83
[Retry]
[Abnormal_code]
[State]
Ignore the number since it is not clear
which number will be displayed
Mark on RAM Monitor Error code Meaning
F0 F3
Frequency of retrying of Abnormal Discharge
Temperature(system)
F1 F3
Frequency of retrying of Abnormal Discharge
Temperature(INV)
F2 F3
Frequency of retrying of Abnormal Discharge
Temperature(STD1)
F3 F3
Frequency of retrying of Abnormal Discharge
Temperature(STD2)
F4 E3 Frequency of retrying of Actuation of High Pressure Sensor
F5 E4 Frequency of retrying of Actuation of High Pressure Sensor
F6 E6 Frequency of retrying of Actuation of High HPSL
F7 E0
Frequency of retrying of STD1 Compressor Motor
Overcurrent/Lock
F8 E0
Frequency of retrying of STD2 Compressor Motor
Overcurrent/Lock
F9 E5 Frequency of retrying of Inverter Compressor Motor Lock
F10 L9 Frequency of retrying of Faulty INV Compressor Startup
F11 L8 Frequency of retrying of Inverter Compressor Overload
F12 L5
Frequency of retrying of Inverter Compressor instantaneous
Overcurrent
F13 U2 Frequency of retrying of Abnormal Power Supply Voltage
F14 L4
Frequency of retrying of Malfunction of Inverter Radiating Fin
Temperature Rise
F17 P1 Frequency of retrying of Power Supply Voltage Imbalance
F21 E7
Frequency of retrying of Malfunction of Outdoor Unit Fan1 Motor
F22 H7
Frequency of retrying of Abnormal Outdoor Unit Fan1 Motor Signal
F24 E7
Frequency of retrying of Malfunction of Outdoor Unit Fan2 Motor
F25 H7
Frequency of retrying of Abnormal Outdoor Unit Fan2 Motor Signal
Mark on RAM Monitor Meaning
Abnormal_code It depends on the table below
Abnormal code
on service
manual
Display on
Ram monitor
screen
Abnormal code
on service
manual
Display on
Ram monitor
screen
Abnormal code
on service
manual
Display on
Ram monitor
screen
E0 30 H3 43 L1 71
E1 31 H7 47 L4 74
E2 32 H9 49 L5 75
E3 33 J2 62 L8 78
E4 34 J3 63 L9 79
E5 35 J5 65 LC 7C
E7 37 J8 68 P1 81
E9 39 J9 69 P4 84
F3 53 JA 6A PJ 8D
H0 40 JC 6C U1 91
U2 92
Mark on RAM Monitor Meaning
State1 Normal when 5 or 9 is display
State2 Normal when 17 is display
