![Haier AC242ACEAA [286/408] Electrical wiring diagram and pcb photo](/img/pdf.png)
Haier AC242ACEAA [286/408] Electrical wiring diagram and pcb photo
![Haier AU122AEERA [286/408] Electrical wiring diagram and pcb photo](/views2/1807985/page286/bg11e.png)
CN1
CN2
CN3
CN4
CN6
CN5
CN8
SW4
SW2
SW6
SW1
CN19
CON1
CON3
CON2
CN18
CN17
CON4
CON5
CN16
CN15
CN14
CN13
CN12
LED1
LED2
CN11
CN10
CN9
SW3
SW5
CN7
Outdoor PCB 0151800054
LED1 red light:power indicator and failure alarm lamp.when outdoor is normal,LED1 is on,or falsh when
failure occurs.
LED2 green light:communication indocator lamp.when communication between indoor and outdoor is
normal,LED2 will be on,or will be off.
Electrical wiring diagram and PCB photo
-269-
