Haier AC242ACEAA [81/408] Air velocity distribution
![Haier AD242ALEAA [81/408] Air velocity distribution](/views2/1807985/page81/bg51.png)
Air Velocity Distribution
Cooling
Blowy angle:25
Temperature Distribution
Cooling
Blowy angle:25
PV
PV
PV
Ceiling
a. Cooling / Air Velocity Distribution
b. Cooling / Temperature Distribution
Heating
Blowy angle:65
Air velocity Distribution
Temperature Distribution
Heating
Blowy angle:65
PV
c. Heating / Air Velocity Distribution
d. Heating / Temperature Distribution
2)
Air velocity distribution
-71-
