Haier AC242ACEAA [323/408] Electric control functions

When compressor is running, air flow is SSLO.

When compressor stops, in 20 seconds, air flow is SSLO, and then turn into ultra low.

4.2 Soft cooling

Air flow is SSLO.

4.3 Not available for Fan, Dry mode.

5. Negative ion function

1) When receiving the command, if fan motor is running, the negative ion generator will work to realize the

negative ion emission function.

2) If fan motor stops, the negative ion generator is OFF.

3) When negative ion generator is OFF, at this time, if you set the negative ion function, when fan motor begins

to runs again, the negative ion generator will be ON automatically.

6. TIMER operation

1) Count the time according to the difference between TIMER CLOCK and the present CLOCK time.

2) When TIMER function works, the TIMER lamp on the indicator board is ON.

3) TIMER OFF

When TIMER OFF is set, the indication on the panel will not change (background lamp is OFF), the timer icon will

display. When timer clock arrives, the operation will stop.

4) TIMER ON

When TIMER ON is set, the indication on the panel only displays the TIMER icon(background lamp is OFF),

When timer clock arrives, the unit will run at the set state.

5) TIMER ON/OFF

The operation will be performed as the set state.

7. SLEEP operation

Sleep function: energy saving function at night, TIMER lamp will be ON.

7.1 Standard sleep function: in cooling or dry mode, after running at SLEEP mode for 1 hour, the set temperature

will rise 1ć, another 1 hour later, the set temperature will rise another 1ć; the unit continues running for 6 hours,

then the unit will stop.



7.2 Standard sleep function: in heating mode, after running at SLEEP mode for 1 hour, the set temperature

reduces 2ć, another 1 hour later, the set temperature will reduce 2ć, and another 3 hours later, the set

temperature rises 1ć; the unit continues running for 3 hours, then the unit will stop.

7.3 Non-standard SLEEP function: the sleep function can realize 1~8 hours sleep mode when being combined

with the TIMER function.

1˅ When in Auto mode, the unit will make SLEEP operation due to the setting.

Ts+ 1

Ts+ 2

Ts- 2

Ts- 3

Ts- 4

Electric control functions

-306-
