Haier AC242ACEAA [45/408] Part name
![Haier AU282AHERA [45/408] Part name](/views2/1807985/page45/bg2d.png)
Drain Hose
Swing fender
Refrigerant pipe
Cable line
Earthing line
Air filter
Outlet
Suction grill
(located in the suction grill)
In cooling operation, to
discharge the water
from inside the room.
Discharge unit (built in)
(located in the outlet)
For AB242ACEAA, AB282ACEAA, AB242ACERA
Swing louver
(Air flow direction can be adjusted by using
the SWING button on the remote controller)
Air Inlet Grille
Air Filter
(Inside of the Inlet Grille)
Operating Control Panel
5. Part name
For AB122ACEAA, AB182ACEAA, AB122ACERA, AB182ACERA
Part Name
-39-
