Smart Power
Item Model 1UH160P1ERG
Power cable H05RN-F 3G 6.0mm2
Communication cable /
Connecting cable H05RN-F 4G 2.5mm2
Power source N, V, Hz 1PH~,220
～
240, 50/60Hz
Start Current A 3
Outdoor
unit
Unit model (color) 1UH160P1ERG(WHITE)
Compressor
Model / Manufacture/place
MNB42FFAMC-LMITSUBISHI
ELECTRIC /Guang Zhou
Oil model PVE(FV50S)
Oil charging 1600CM3
Type Twin Rotary 1
Fan
Type × Number Axial×2
Speed r/min 700±40
Fan motor input power kW 0.12×2
Fan motor output power kW 0.10×2
Air-ow(H-M-L) m³/h 7500
Heat exchanger
Type / Diameter mm TP2M/Φ7.0
Row/Fin pitch 2 1.4
Total area m² 1.17
Dimension
External(W×D×H) mm×mm×mm 950/370/1350
Package(W×D×H) mm×mm×mm 1023/485/1500
Drainage pipe (material , I.D./O.D.) mm None
Refrigerant control method mm/mm
E L E C T R O N I C V A V E
3.0MM
Defrosting Auto
Volume of accumulator L 4.0
Sound power noise level (H-M-L) dB(A) 73
Sound pressure noise level (H-M-L) dB(A) 57
Type of Four way valve SHF-20D-46
material of reduce noise XPE
crankcase heater power W 38
Weight(Net / Shipping) kg / kg 105/118
PIPING
Refrigerant
Type / Charge g R410A/3700
Maximum pipe length
without recharge refrigerant
m 30
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Connecting Method Flared
Between I.D &O.D
MAX.Drop m 30
MAX.Piping length m 75
Norminal condition:
indoor temperature (cooling): 27°C DB/19°C WB, indoor temperature (heating): 20°CDB
Outdoor temperature(cooling): 35°C DB/24°C WB, outdoor temperature(heating): 7°CDB/6°CWB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated
sound intensity meter. It is a sound pressure noise level.
