164
Smart Power
ADH200H1ERG ADH250H1ERG PCB code: 0151800106EH
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 Description
OFF OFF OFF -- -- -- -- -- ADH200H1ERG
ON OFF OFF -- -- -- -- -- ADH250H1ERG
-- -- -- OFF -- -- -- -- Room card invalid(default)
-- -- -- ON -- -- -- -- Room card valid
-- -- -- -- OFF -- -- -- Cool and heat(default)
-- -- -- -- ON -- -- -- Cool only
-- -- -- -- OFF ON OFF Medium ESP DUCT(deafult)
-- -- -- -- ON ON OFF High ESP DUCT
Wired controller communication address
SW2-1 SW2-2 SW2-3 SW2-4
Indoor unit Address
(Indoor unit address for one wired controller control more than one
unit)
OFF OFF OFF OFF 0 (master)
OFF OFF OFF ON 1(slave)
OFF OFF ON OFF 2(slave)
OFF OFF ON ON 3(slave)
OFF ON OFF OFF 4(slave)
OFF ON OFF ON 5(slave)
OFF ON ON OFF 6(slave)
OFF ON ON ON 7(slave)
ON OFF OFF OFF 8(slave)
ON OFF OFF ON 9(slave)
ON OFF ON OFF 10(slave)
ON OFF ON ON 11(slave)
ON ON OFF OFF 12(slave)
ON ON OFF ON 13(slave)
ON ON ON OFF 14(slave)
ON ON ON ON 15(slave)
