Smart Power

(4) In central or lock state, screen saving is valid; press any key to wake up screen.

(5) In central or lock state, malfunction inquiry, indoor unit parameter inquiry and child lock are valid.

Energy Saving Parameter Setting

(1)Under cooling mode 30°C, keep pressing key for 5 seconds to set energy saving parameter in cooling mode.

This cooling energy saving parameter is ashing behind top-left colon. The default value is 23°C. This lowest target

cooling temperature can be adjusted by . After setting, press key to conrm and exit.

(2) Under heating mode 16°C, keep pressing key for 5 seconds to set energy saving parameter in heating

mode. This heating energy saving parameter is ashing behind top-right colon. The default value is 26°C. This

highest target heating temperature can be adjusted by . After setting, press key to conrm and exit.

(3) Energy saving parameter will be valid after energy saving icon displays.

Non-volatile Memory

(1) Set valid or invalid non- volatile memory through dip switch Sw4.

(2) Info memorized: Mode, Fan Speed, Temp. Setting, Swing State, Heat Reclaim Ventilation function.

(3) If timer or sleeping is set, it will be in OFF state after electried again; it will memorize all the state before power

failure except ON/OFF state.

(4) For easy maintenance, no matter non-volatile memory is valid or invalid, malfunction record will be remembered.

Communication Malfunction of Wired Controller

If there is no communication between wired controller and indoor unit for 4 minutes, it will display error code “07”

when checking malfunction.

Sensor Malfunction

If the dip switch is set to collect ambient Temp. from wired controller and the sensor can’t work normally, it will

display error code “01” when checking malfunction.

Temp. Compensation Setting

(1) In OFF state, keep pressing key for 5 seconds, the current temp. compensation value is displayed on the

top-right of the screen and ashes. “00” is the default value.

(2) When in celsius system, ambient compensation value is -04~+04, while in fahrenheit system, ambient

compensation value being -07~+07. The temp. compensation value can be adjusted by pressing .

(3) After adjustment, press key to conrm the setting.

(4) The compensation value is used for ambient temp..

(5) The compensation value is valid only in the state of collecting ambient temp. of wired controller.

Forced Cooling/ Heating

(1) Powered off in cooling mode, keep pressing “ON/OFF” key for 10 seconds, it will enter into the forced cooling

function, and the cooling mode icon will be displayed on the interface. “LL” is ashing in the temp. area at the same

time. Press “ON/OFF” key to power off and exit forced cooling.

(2) Powered off in heating mode, keep pressing “ON/OFF” key for 10 seconds, it will enter into the forced heating

function, and the heating mode icon will be displayed on the interface, “HH” is ashing in the temp. area at the

same time. Press “ON/OFF” key to power off and exit forced heating.

(3) All the keys are invalid except “ON/OFF” key under forced cooling/heating mode, which can be cancelled by

powering off manually or receiving “trial operation” nished order from the communication. The former one can

operate power off directly while the later one will make the controller do by following the order.
