36
Smart Power
Item Model ADH090M1ERG/1UH090N1ERG
Function Cooling Heating
Capacity kW 8.5 (2.5~10) 9.5 (2.5~11)
Sensible heat ratio 0.72 /
Total power input kW 2.50 (0.5~4.4) 2.50 (0.5~4.4)
Max. power input W 4400 4400
AEER or ACOP W/W 3.33 3.72
Dehumidifying capacity 10
-3
×m
3
/h 2.5
Power cable 4.0mm
2
Power source N, V, Hz 1, 220-240, 50/60
Running/Max. Running current A/A
11.1 (2.3-19.2) /19.2 11.1 (2.3-19.2) /19.2
Start current A 3
Circuit breaker A
1Ph，30A（from outdoor)
Indoor
unit
Unit model (color) ADH090M1ERG
Fan
Type×Number CENTRIFUGALX2
Speed (H-M-L) r/min 1020/920/820
Fan motor output/ input power W 112/147
Air-ow (H-M-L) m
3
/h 1300/900/700
External static pressure Pa 10/30(default)/50/70
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Row 3
Total area m
2
/
Dimension
External (L×W×H) mm×mm×mm 957/655/250
Package (L×W×H) mm×mm×mm 1170/860/340
Drainage pipe (material, I.D./O.D.) mm PVC 25/29
Controller (O-Optional, S-Standard)
Wired YR-E16A(O)/YR-E17(S)
Infrared YR-HBS01(O)
Fresh air hole dimension mm 145
Electricity heater kW NONE
Sound power noise level (H) dB (A) 60
Sound pressure noise level (H-M-L) dB (A) 40/37/34
Piping
Refrigerant
Type / Charge g R410A/2500
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Max.pipe lengh without
charge refrigerant
m 20
Between
I.D &O.D
MAX.Drop m 30
MAX.Piping length m 50
Connecting method Flared
Cooling Pdesignc (kW): 8.5kW SEER/CLASS 6.1/A++
QCE(Annual electricity
consumption for cooling)kWh:
485
Heating
Average Pdesignh (-10°C) 7.0kW SCOP/CLASS
4.1/A+
QHE(Annual electricity
consumption for heating)kWh:
2256
Warmer Pdesignh (2°C) 7.8kW SCOP/CLASS
4.8/A++
1928
Colder Pdesignh (-22°C) / SCOP/CLASS
/
/
Tdesignh: -10°C Tbivalent: -10°C TOL: -15°C Elbu: 0
Max. cooling
condition
Indoor temperature: 32°C/23°C
Max. heating condition
Indoor temperature: 27°C/-°C
Outdoor temperature: 46°C/-°C Outdoor temperature: 24C/18C
Norminal condition:
Indoor temperature (cooling) : 27DB (°C)/19WB (°C) , Indoor temperature (heating) : 20DB (°C)
Outdoor temperature (cooling) : 35DB (°C)/24WB (°C) , Outdoor temperature (heating) : 7DB (°C)/6WB (°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity
meter. It is a sound pressure noise level.
