Smart Power

Item Model ADH200H1ERG/1UH200W1ERK

Function Cooling Heating

Capacity kW 20.5(6.2-23.5) 22.8(7.2-24.8)

Sensible heat ratio / /

Total power input kW 6.1(2.5-8.5) 6.0(2.5-8.5)

Max. power input W 8500 8500

EER or COP W/W 3.36 3.8

Dehumidifying capacity 10

-3

×m³/h 5.9

Power source N, V, Hz 1PH, 220-230V~, 50/60Hz

Running /Max.Running current A / A 11(2.2-15.3)/15.3 11(2.2-15.3)/15.3

Start Current A /

Circuit breaker A

3Ph, 40A（from outdoor）

Indoor unit

Unit model (color) ADH200H1ERG/(grey)

Fan

Type × Number CENTRIFUGALX2

Speed(H-M-L) r/min 1060/980/900

Fan motor input power W 980/1000

Fan motor output power Pa 62PA (default)

Air-ow(H-M-L) m³/h 4320/3780/3420/3060

Heat

exchanger

Type/Diameter mm Inner grooved pipe/φ7.0

Row 4

Total area m² /

Dimension

External(L×W×H) mm×mm×mm 1330/895/500

Package(L×W×H) mm×mm×mm 1510/1037/568

Drainage pipe (material, I.D./O.D.) mm Hot zinc plate 23/25

Controller (O-Optional,S-Standard)

Wired(S) YR-E17(S) OR YR-E16A(O)

Infrared(O) YR-HBS01

Fresh air hole dimension mm /

Electricity heater kW NONE

Sound power noise level (H-M-L) dB(A) 68

Sound pressure noise level (H-M-L) dB(A) 54/50/45

Pipe

Liquid pipe mm 12.7

Gas pipe mm 19.05

Connecting method ared

Weight (Net / Shipping) kg / kg 96/125

Tdesignh: -10°C Tbivalent: -10°C TOL:-15°C Elbu:0

Max. cooling condition

Indoor temperature:18~32°C

Max. heating

condition

Indoor temperature:27 °C/ -°C

Outdoor temperature:-10~46°C

Outdoor temperature:24°C/ 18°C

Norminal condition:

indoor temperature (cooling): 27°C DB/19°C

WB, indoor temperature (heating): 20°C DB

Outdoor temperature (cooling): 35°C DB/24°C WB, outdoor temperature (heating): 7°C DB/6°C WB

The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated

sound intensity meter. It is a sound pressure noise level.
