![Haier 1UH071N1ERG [160/238] Smart power](/views2/1812262/page160/bga0.png)
158
Smart Power
LED1 LED1 \
Power indicate or indoor PCB &wired
controller
1.Power indicate:with power at least one
of them ash or lit,without power: none of
them ash or lit
LED2 LED2 \ \
2.Indoor&outdoor communication
indicate:LED1 and LED2 keep ashing
alternately
LED3 LED3 \ \
1.Power indicate:with power at least one
of them ash or lit, without power:none of
them ash or lit
2.Error indicate: only LED3 ashes--indoor
error; LED4 ash M times then LED3 ash
N times--outdoor error
3.Indoor&outdoor communication indicate:
LED4 and LED3 keep ashing alternately
LED4 LED4 \
Power indicate or error indicate or
indoor&outdoor communication indicate
SW1 SW1 \ Model and function selection Details refer to service manual
SW2 SW2 \ Wired controller address selection Details refer to service manual
