49
Product Specifications
GSE520 GSE550
Sensor 5 Mega pixels CMOS
Lens 120 degree
Focus 10cm – infinity
GPS NO Internal antenna
Video output
Mini HDMI: Support 1080i/720p output mode
Composite: NTSC/PAL
Recording format MOV
Recording resolution
1920x1080(30fps) 、 1280x720(30fps) 、
848x480(60fps)
Video Codec H.264
Recording media
Micro SD Card(Up to 64GB SDHC Card)
Laser LED Light 1 PCS
File protection NO YES
USB Micro USB
Imposition of date /
time on video
YES
Size 64mm X 68mm X 37mm
Weight 93g
Nutrition DC 12-24V
Working humidity 10%~80%
Temperature
-10℃~70℃
※Actual specifications depend on factory announcement. No further notice will be
provided in case of any change.
