2.2 WH-MDF12C9E8
Item Unit Refrigerant System
Performance Test Condition
EUROVENT
kW 12.00
BTU/h 40900
Heating Capacity
kcal/h 10320
W/W 4.67
COP
kcal/hW 4.02
Air Flow
m
3
/min (ft
3
/min) 80.0 (2830)
Refrigeration Control Device
Expansion Valve
Refrigeration Oil
cm
3
FV50S (1200)
Refrigerant (R410A)
kg (oz) 2.30 (81.2)
Liquid
mm (inch) 9.52 (3/8)
Pipe Diameter
Gas
mm (inch) 15.88 (5/8)
Type
Hermetic Motor
Motor Type
Brushless (4-poles)
Compressor
Rated Output
kW 4.30
Type
Propeller Fan
Material
PP
Motor Type
Induction (8-poles)
Input Power
W —
Output Power
W 60
Fan
Fan Speed
rpm 510 (Top Fan) 550 (Bottom Fan)
Fin material
Aluminium (Pre Coat)
Fin Type
Corrugated Fin
Row × Stage × FPI
2 × 51 × 18
Heat Exchanger
Size (W × H × L)
mm 881.5 × 1295.4 × 44
Item Unit Monobloc Unit
Height
mm (inch) 1410 (55.5)
Width
mm (inch) 1283 (50.5)
Dimension
Depth
mm (inch) 320 (12.6)
Net Weight
kg (lbs) 157 (346)
dB-A 50
Noise Level
Power Level dB 67
ø Three
V 400
Power Source (Phase, Voltage, Cycle)
Hz 50
Input Power
kW 2.57
Starting Current
A 3.9
Running Current
A 3.9
Max. Current/Max. Input Power Heatpump unit
(Heatpump unit + Back-up Heater)
A/kW 8.8 / 5.85 (Separate ELCB)
Back-up Heater: Max. Current/Max. Input Power
A/kW 13.0 / 9.00
Tank Heater [1 Phase, 230V]: Max. Current/
Max. Input Power
A/kW 13.0 / 3.00
Power Factor
% 96
Power factor means total figure of compressor and outdoor fan motor.
Number of core -
Power Cord
Length m (ft) -
Thermostat
Electronic Control
Protection Device
Electronic Control
