8
Item Unit Water System
Performance Test Condition
EUROVENT
Outdoor Ambient °C -20 ~ 35
Operation Range
Water Outlet °C 25 ~ 55
Internal Pressure Differential
kPa 27.5
Liquid mm (inch) 9.52 (3/8)
Refrigerant Pipe Diameter
Gas mm (inch) 15.88 (5/8)
Inlet mm (inch) 30 (1-3/16)
Water Pipe Diameter
Outlet mm (inch) 30 (1-3/16)
Water Drain Hose Inner Diameter
mm (inch) 15.00 (19/32)
Motor Type Capacitor Run Induction Motor (5 μF)
No. of Speed 3
Pump
Input Power W 180
Type Brazed Plate
No. of Plates 60
Size (W x H x L) mm 93 × 100 × 325
Hot Water Coil
Water Flow Rate l/min (m
3
/h) 34.4 (2.1)
Pressure Relief Valve Water Circuit
kPa Open: 190, Close: 186 and below
Flow Switch
Magnetic Lead Switch
Protection Device
A Residual Current Circuit Breaker (40)
Volume I 10
Expansion Vessel
MWP bar 1
Capacity of Integrated Electric Heater
kW 9.00
Note:
Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb
(42.8°F Wet Bulb) with controlled water inlet temperature of 30°C and water outlet temperature of 35°C.
Specification are subjected to change without prior notice for further improvement.
