8.2.3. Protection Control For Heating Operation
8.2.3.1. Anti Cold Draft Control
Indoor fan speed varies in accordance to indoor heat exchanger temperature, based on type of air volume and direction, as shown
below.
1. Manual Fan Speed
2. Auto Fan Speed
35
CS-XE9CKE CU-XE9CKE / CS-XE12CKE CU-XE12CKE
