Panasonic CU-XE9CKE [56/110] Preparations
![Panasonic CU-XE9CKE [56/110] Preparations](/views2/1832883/page56/bg38.png)
After several seasons and due to operational conditions, performance may be reduced by dust or there may be
unpleasant smells.
Recommended Inspections
Consult an authorized distributor for inspection!
Same type!
OPEN front panel
Insert batteries
Set clock
Pre-season inspection
PREPARATIONS
Installation: see enclosed installation instruction!
Press button
Plug/breaker
2-3[h]
For extended
non-operation
dry internal partsSTART
Unplug
Remove batteries
OFF
Remove AIR filters Place PURIFYING filter
Place AIR filters
CLOSE front panel
Plug in
Call Service
ервиз
Καλέστε τον αντιπρσωπο
вызовите сервис
~15
Min.
Open / remove
Rechargeable
Insert batteries / close
–
+
Check
~1
Use
Year
Press
Set time
Set current time immediatel Confirm
Check
1.
Fans obstructed?
OK?
2.
Batteries
START cooling or heating
Check performance
–
~ 8˚C (COOL)
~ 14˚C (HEAT)
Call Service
refer page 59
Batterij niet weggooien, maar inleveren als KCA
Indoor unit
56
CS-XE9CKE CU-XE9CKE / CS-XE12CKE CU-XE12CKE
