Outdoor Unit
30 seconds Forced Operation
Time Delay Safety Control
Overload Protection
Deice Operation
Compressor Overheating
Prevention Control
IPM (Power Transistor)
Overheating Protection Control
Total Running Current Control
Low Operation Frequency
Protection Control
Outdoor Air Temperature
Control
5
CS-XE9CKE CU-XE9CKE / CS-XE12CKE CU-XE12CKE
