120
<Model: WH-SDF09C3E8 WH-SDF12C9E8 WH-SDF14C9E8 WH-SDF16C9E8>
REF.
NO.
DESCRIPTION & NAME QTY. WH-SDF09C3E8 WH-SDF12C9E8 WH-SDF14C9E8 WH-SDF16C9E8 REMARKS
1 BASE PAN 1 CWD521266 ← ← ←
2 HOT WATER COIL-COMPLETE 1 CWB90C1051 ← ← ← O
3 RECEIVER 1 CWB141039 ← ← ←
4 FLOAT (FLOW SWITCH) 1 CWB601008 ← ← ← O
6 FLARE NUT (3/8) 1 CWT251061 ← ← ←
7 FLARE NUT (5/8) 1 CWT251064 ← ← ←
9 PUMP 1 CWB532096 ← ← ← O
10 PACKING (O-RING) I.D 32mm 2 CWB811082 ← ← ←
11 PACKING (O-RING) I.D 13.8mm 2 CWB811022 ← ← ←
12 RETAINING RING D:22mm 1 CWH581007 ← ← ←
16 BOTTLE COMPLETE 1 CWH90C0011 ← ← ←
17 HEATER ASS'Y 1 CWA34C1023 CWA34K1021 ← ← O
18 SOUND PROOF MATERIAL 1 CWG302575 ← ← ←
19 THERMOSTAT 4 CWA151065 ← ← ← O
20 ELECTRONIC CONTROLLER-MAIN 1 CWA73C5108 CWA73C5109 CWA73C5110 CWA73C5111 O
21 TERMINAL BOARD ASS'Y 1 CWA28K1240 ← ← ←
25 TERMINAL BOARD ASS'Y 1 CWA28K1229 ← ← ←
26 TERMINAL BOARD ASS'Y 1 CWA28K1230 ← ← ←
27 ELECTRO MAGNETIC SWITCH 1 K6C1AYY00004 ← ← ← O
28 TERMINAL BOARD ASS’Y 1 CWA28K1231 ← ← ←
29a
RESIDUAL CURRENT CIRCUIT
BREAKER
1/2 CWA181008 ← ← ←
29
RESIDUAL CURRENT CIRCUIT
BREAKER
1 CWA181005 ← ← ← O
30 TRANSFORMER-COMPLETE 1 CWA40C1075 ← ← ← O
31 SENSOR-COMPLETE 1 CWA50C2762 ← ← ← O
32 REMOTE CONTROL COMPLETE 1 CWA75C3656 ← ← ← O
33 PRESSURE GAUGE 1 CWB070001 ← ← ← O
34 PRESSURE RELIEF VALVE 1 CWB621011 ← ← ← O
35 CABINET 1 CWE001050A ← ← ←
36 HANDLE 2 CWE161008 ← ← ←
37 CABINET FRONT PLATE 1 CWE061265A ← ← ←
38 INSTALLING HOLDER 1 CWH361103A ← ← ←
39 OPERATING INSTRUCTION 1 CWF567539 ← ← ←
40 INSTALLATION INSTRUCTION 1 CWF614485 ← ← ←
41 TUBE CONNECTOR-COMPLETE 1 CWT29C1043 ← ← ←
42 ACCESSORY-COMPLETE 1 CWH82C1754 ← ← ←
Note:
All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
“O” marked parts are recommended to be kept in stock.
