![Panasonic WH-SDF16C9E8 [40/125] Wire stripping and connecting requirement](/img/pdf.png)
Panasonic WH-SDF16C9E8 [40/125] Wire stripping and connecting requirement
![Panasonic WH-SDF16C9E8 [40/125] Wire stripping and connecting requirement](/views2/1833109/page40/bg28.png)
40
Terminal screw Tightening torque N•cm {kgf•cm}
M4 157~196 {16~20}
M5 196~245 {20~25}
11.3.4.1 Wire Stripping and Connecting Requirement
