124
<Model: WH-UD09CE8 WH-UD12CE8 WH-UD14CE8 WH-UD16CE8>
REF. NO. DESCRIPTION & NAME QTY. WH-UD09CE8 WH-UD12CE8 WH-UD14CE8 WH-UD16CE8 REMARKS
1 BASE PAN ASS’Y 1 CWD52K1200 ← ← ←
2 COMPRESSOR 1 5JD420XBA22 ← ← ← O
3 ANTI-VIBRATION BUSHING 3 CWH50055 ← ← ←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ← ← ←
4a PACKING 3 CWB811017 ← ← ←
5 CRANKCASE HEATER 1 CWA341053 ← ← ←
6 CONDENSER COMPLETE 1 CWB32C3035 ← ← ←
7 HIGH PRESSURE SENSOR 1 CWA50C2570 ← ← ←
8 DISCHARGE MUFFLER 1 CWB121014 ← ← ←
9 PRESSURE SWITCH 1 CWA101013 ← ← ←
10 3-WAYS VALVE (GAS) 1 CWB011251 ← ← ←
11 4-WAYS VALVE 1 CWB001046 ← ← ←
12 3-WAYS VALVE (LIQUID) 1 CWB011292 ← ← ←
13 STRAINER 2 CWB111032 ← ← ←
19 ACCUMULATOR ASS’Y 1 CWB131026A ← ← ←
20 SOUND PROOF MATERIAL - COMP 1 CWG302265 ← ← ←
21 SOUND PROOF MATERIAL 1 CWG302266 ← ← ←
22 SOUND-PROOF BOARD ASS’Y 1 CWH15K1031 ← ← ←
23 V-COIL COMPLETE - 4-WAYS VALVE 1 CWA43C2169J ← ← ← O
24 V-COIL COMPLETE - EXP. VALVE 1 CWA43C2385 ← ← ← O
25 SENSOR-OD TEMP./COIL 1 CWA50C2730 ← ← ←
26 SENSOR-COMP.DISCHARGE 1 CWA50C2576 ← ← ←
27 SENSOR-COMP. TOP 1 CWA50C2629 ← ← ←
27a SENSOR-COMP. DEF. 1 CWA50C2577 ← ← ←
28 CABINET REAR PLATE 1 CWE02C1059 ← ← ←
29 CONTROL BOARD CASING 1 CWH10K1133 ← ← ←
31 TERMINAL BOARD ASS’Y 1 CWA28K1214 ← ← ←
38
ELECTRONIC CONTROLLER (NOISE
FILTER)
1 CWA745822 ← ← ← O
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C5074R CWA73C5075R CWA73C5076R CWA73C5077R O
46 REACTOR 3 G0C293J00001 ← ← ←
48 TERMINAL COVER 1 CWH171039A ← ← ←
49 NUT FOR TERMINAL COVER 1 CWH7080300J ← ← ←
50 BRACKET FAN MOTOR 1 CWD54K1024 ← ← ←
50a SCREW-BRACKET FAN MOTOR 2 CWH551040J ← ← ←
53 FAN MOTOR (UPPER) 1 EHDS80AAC ← ← ← O
54 FAN MOTOR (LOWER) 1 EHDS80BAC ← ← ← O
54a SCREW-FAN MOTOR 8 CWH551016J ← ← ←
55 PROPELLER FAN 2 CWH00K1006 ← ← ←
56 NUT for PROPELLER FAN 2 CWH561051 ← ← ←
57 CABINET FRONT PLATE 1 CWE061098A ← ← ←
58 DISCHARGE GRILLE 2 CWE201073 ← ← ←
59 CABINET SIDE PLATE 1 CWE04K1023A ← ← ←
60 WIRE NET 1 CWD041103A ← ← ←
61 CABINET TOP PLATE COMPLETE 1 CWE03C1096 ← ← ←
62 ACCESSORY COMPLETE 1 CWH82C1535 ← ← ←
64 PIPE COVER (FRONT) 1 CWD601074A ← ← ←
65 PIPE COVER (BACK) 1 CWD601075A ← ← ←
66 CABINET FRONT PLATE COMPLETE 1 CWE06C1091 ← ← ←
67 HANDLE 2 CWE161008 ← ← ←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1541 ← ← ←
70 EXPANSION VALVE 1 CWB051028 ← ← ←
