Diagnosis display Abnormality/Protection control Abnormality judgement Primary location to verify

F41 PFC control 4 times occurrence within 10

minutes

 Voltage at PFC

F42 Outdoor heat exchanger temperature

sensor abnormality

Continue for 5 sec.

 Outdoor heat exchanger temperature

sensor (defective or disconnected)

F43 Outdoor defrost sensor abnormality Continue for 5 sec.

 Outdoor defrost sensor (defective or

disconnected)

F45 Indoor water outlet temperature sensor

abnormality

Continue for 5 sec.

 Water outlet temperature sensor

(defective or disconnected)

F46 Outdoor Current Transformer open

circuit

—

 Insufficient refrigerant

 Outdoor PCB

 Compressor low

F95 Cooling high pressure overload

protection

—

 Outdoor high pressure sensor

 Water pump or water leakage

 Clogged expansion valve or strainer

 Excess refrigerant

 Outdoor PCB
