11
2. Turn the rotary switch to , or .
3. Press SELECT to toggle between AC/DC.
4. Break the circuit path to be measured, connect
the test leads across the break and apply
power.
5. Read the measured current on the display.
Measure Resistance
1. Connect the black test lead to the COM
Terminal and the test lead to the VΩHz
Terminal.
2. Turn the rotary switch to , and the display
will show “ ”.
3. Touch the probes to the desired test points of
the circuit to measure the resistance.
4. Read the measured resistance on the display.
*Do not measure current that exceeds the extremes
as indicated in the Specifications.
*Use the 20A Terminal and the Mode when you
are measuring an unknown current. Then switch
to the mA μA Terminal and the Mode or the
Mode if necessary.
*Do not input voltage at this setting.
