![Zotek ZT-219 [24/28] Electrical specifications](/views2/1893224/page24/bg18.png)
Electrical Specifications
Function Range
Resolution
Accuracy
DC Voltage
(V)
1.9999V
0.0001V
±(0.05%+3)
19.999V
0.001V
199.99V
0.01V
1000.0V
0.1V
DC Voltage
(mV)
19.999mV
0.001mV
199.99mV
0.01mV
AC Voltage
(V)
1.9999V
0.0001V
±(0.3%+3)
19.999V
0.001V
199.99V
0.01V
750.0V
0.1V
AC Voltage
(mV)
19.999mV
0.001mV
199.99mV
0.01mV
DC Current
(A)
1.9999A
0.0001A
±(0.5%+3)
19.999A
0.001A
20
