4
⑧
Duty cycle test.
⑨
Resistance test.
(Ohm)
⑩
Frequency test. (Hertz)
⑪
Current test. (Ampere)
⑫
Voltage test. (Volt)
⑬
Capacitance
test. (Farad)
⑭
Temperature test.
(Fahrenheit or Celsius)
⑮
Auto range. The product selects
the range with the best resolution.
⑯
The product measures both
sinusoidal and nonsinusoidal ac
waveforms accurately.
⑰
Low battery. Replace batteries.
⑱
Negative readings.
⑲
Alternating current.
⑳
Direct current.
Measurement units.
