Function Buttons
①
②
③ ④ ⑤
⑥
①
Selects alternate measurement modes on a
rotary switch setting, including:
1. DC mV/AC mV/Temperature
2. Resistance/Continuity/Diode/Capacitance
3. Frequency/Duty Cycle
4. DC A/AC A
5. DC mA/AC mA
6. DC
μA/AC μA
②
Push
once to hold the current reading on
the
display
; push again to continue
normal
operation
.
Push
for more than 2 seconds to turn on
the
backlight
; long-push again to turn off or
the
backlight
automatically turns off after
2
minutes
.
