Zotek ZT-219 [12/28] Ac voltage 750v
![Zotek ZT-219 [12/28] Ac voltage 750v](/views2/1893224/page12/bgc.png)
88
AC voltage
≤750V
Press RANGE button:
Frequency with high voltage
Duty Cycle from 1%~99%
DC voltage ≤1000V
DC voltage ≤199.99mV
AC voltage ≤199.99mV
Celsius:
-20~1000
Fahrenheit:
-4~1832
Ohms
≤200MΩ
Continuity. Beeper turns on at
＜50Ω
Diode test. Displays above 3V
Farads
≤9.999mF
Frequency with low voltage
Duty Cycle from 1%~99%
DC A from ≤19.999A
AC A from ≤
19.999A
DC A from ≤199.99mA
AC A from ≤199.99m
A
DC A from ≤1999.9
μA
AC A from ≤1999.9
μA
Non
-contact voltage test.
