10
Measurements Instruction
Measure AC/DC Voltage
1. Connect the black test lead to the COM
Terminal and the red lead to the VΩHz
Terminal.
2. Turn the rotary switch to , , or .
3. Press SELECT to toggle between AC/DC.
4. Touch the probes to the correct test points of
the circuit to measure the voltage.
5. Read the measured voltage on the display.
Measure AC/DC Current
1. Connect the black test lead to the COM
Terminal and the red lead to the mA μ A
Terminal or the 20A Terminal (choose based
on the value of the current to be measured).
*Do not measure voltage that exceeds the extremes
as indicated in the Specifications.
*Do not touch high voltage circuit during
measurements.
