15
Measure Duty Cycle
1. Connect the black test lead to the COM
Terminal and the red lead to the VΩHz
Terminal.
2. Turn the rotary switch to , press the Hz %
button twice to toggle to the Duty Cycle Mode
(applies to low frequency with high voltage); or
turn the rotary switch to , press SELECT
once times to toggle to the Frequency Mode
(applies to high frequency with low voltage).
3. Touch the probes to the desired test points.
4. Read the measured duty cycle value on the
display.
Measure Temperature
1. Connect the black thermocouple probe to the
COM Terminal and the red probe to the VΩHz
Terminal.ll
