Zotek ZT-219 [10/28] As a reference for subsequent readings the
![Zotek ZT-219 [10/28] As a reference for subsequent readings the](/views2/1893224/page10/bga.png)
6
③
Push
this button once to enter the
manual
range
mode. In manual range mode,
each
push
increases the range; when the
highest
range
is reached, the next push will lead
to
the
lowest range. To exit the manual
range
mode,
push the button for more than
2
seconds
or turn the rotary switch.
④
Push
this button to enter the relative
mode.
The
product will store the present
reading
as
a reference for subsequent readings.
The
display
is zeroed, and the stored reading
is
subtracted
from all subsequent
readings.
Push
again to exit the relative mode.
⑤
Push
to toggle between the MAX and
the
MIN
mode. To exit MAX/MIN mode,
push
the
button for more than 2 seconds.
⑥
Push
this button when the rotary switch is
at
the
position of , the product will
enter
Frequency/Duty
Cycle (only applies to
low
frequency
with low voltage)
measuring
mode
.
