Zotek ZT-219 [16/28] Connect the black test lead to the com
![Zotek ZT-219 [16/28] Connect the black test lead to the com](/views2/1893224/page16/bg10.png)
12
Test for Continuity
1. Connect the black test lead to the COM
Terminal and the red lead to the VΩHz
Terminal.
2. Turn the rotary switch to , press SELECT
once to toggle to the Continuity Mode.
3. Touch the probes to the desired test points of
the circuit.
4. The built-in beeper will beep when the
resistance is lower than 50Ω, which indicates a
short circuit.
Test Diodes
1. Connect the black test lead to the COM
Terminal and the red lead to the VΩHz
Terminal.
*Do not input voltage at this setting.
*Disconnect circuit power and discharge all
capacitors before you test resistance.
*Do not input voltage at this setting.
