14
3. Connect the red probe to the anode side and
the black probe to the cathode side of the
capacitor being tested.
4. Read the measured capacitance value on the
display once the reading is stablized.
Measure Frequency
1. Connect the black test lead to the COM
Terminal and the red lead to the VΩHz
Terminal.
2. Turn the rotary switch to , press the Hz %
button once to toggle to the Frequency Mode
(applies to low frequency with high voltage); or
turn the rotary switch to to enter the
Frequency Mode (applies to high frequency
with low voltage).
3. Touch the probes to the desired test points.
4. Read the measured frequency value on the
display.
*Disconnect circuit power and discharge all
capacitors before you test capacitance.
