Serial Console Server User Manual
146
Specifications
SN0108CO / SN0116CO (AXA Platform)
Function SN0108CO SN0116CO
Serial Connections 8 16
Connectors Serial 8 x RJ45 Female 16 x RJ45 Female
LAN 2 x RJ45
Power 2 x IEC 60320/C14
PON 1 x RJ45 Female (Reserved)
Modem 1 x RJ45 Female
USB 3 x USB Type A Female
USB Console (LUC) 1 x Mini USB
Local Console 1 x RJ45 Female
Switches Reset 1 x Recessed Pushbutton
Power 2 x Rocker Switch
LEDs Serial Port Status 8 (Green) 16 (Green)
10 / 100 / 1000 Mbps 2 (Red / Orange / Green)
Power 2 (Blue)
I/P Rating AC 100–240V~; 50/60Hz; 1A
Power Consumption
AC 110 V:5.3 W
AC 220 V:5.2 W
AC 110 V:5.5 W
AC 220 V:5.5 W
Mode of Operation Console Management, Console Management
Direct, Real Com Port, TCP Server/Client, UDP
Server/Client, Virtual Modem
Environment Operating Temp. 0–40° C
Storage Temp. -20–60° C
Humidity 0–80% RH Noncondensing
Physical Properties Housing Metal
Weight 4.35 kg 4.38 kg
Dimensions L x W x H 43.72 x 32.98 x 4.40 cm
(19”1U)
43.72 x 32.98 x 4.40 cm
(19”1U)
