Appendix
157
3. Select the Serial Console Server in the Device List.
Note: 1. If the list is empty, or your device doesn't appear, click
Enumerate to refresh the Device List.
2. If there is more than one device in the list, use the MAC address
to pick the one you want. The Serial Console Server MAC
address is located on its bottom panel.
4. Select either Obtain an IP address automatically (DHCP), or Specify an
IP address. If you chose the latter, fill the IP Address, Subnet Mask, and
Gateway fields with the information appropriate to your network.
5. Click Set IP.
6. After the IP address shows up in the Device List, click Exit. See IP
Installer, page 103 for more information.
Browser
1. Set your client computer's IP address to 192.168.0.XXX
Where XXX represents any number or numbers except 60. (192.168.0.60 is
the default address of the Serial Console Server.)
2. Specify the Serial Console Server's default IP address (192.168.0.60) in
your browser, and you will be able to connect.
3. Assign a fixed IP address for the Serial Console Server that is suitable for
the network segment that it resides on.
4. After you log out, reset your client computer's IP address to its original
value.
