Serial Console Server User Manual
152
SN0132COD / SN0148COD (AXA Platform)
Function SN0132COD SN0148COD
Serial Connections 32 48
Connectors Serial 32 x RJ45 Female
(Black)
48 x RJ45 Female
(Black)
LAN 2 x RJ-45 (Black)
Power 1 x 5-Pin Terminal Block (Green)
PON 1 x RJ45 Female (Reserved)
Modem 1 x RJ45 Female
USB 3 x USB Type A Female
USB Console (LUC) 1 x Mini USB
Local Console 1 x RJ45 Female
Switches Reset 1 x Recessed Pushbutton
Power 2 x Rocker Switch
LEDs Serial Port Status 32 (Green) 48 (Green)
10 / 100 / 1000 Mbps 2 (Red / Orange / Green)
Power 2 (Blue)
I/P Rating DC 36-48 V DC; 1.6 A in 5-Pin Terminal Block
Power Consumption DC 48V:9.8W DC 48V:10.3W
Mode of Operation Console Management, Console Management
Direct, Real Com Port, TCP Server/Client, UDP
Server/Client, Virtual Modem
Environment Operating Temp. 0–40° C
Storage Temp. -20–60° C
Humidity 0–80% RH Noncondensing
Physical Properties Housing Metal
Weight 4.83 kg 4.89 kg
Dimensions L x W x H 43.84 x 32.77 x 4.40 cm
