Chapter 1. Introduction
5
IPv4 / IPv6 support
Integrates into CC2000 software for centralized data center management
Integrates into CCVSR software for user session recording
Note: SN01xxCO only.
Serial Device Management
Versatile serial operating modes – Console Management, Console
Management Direct, Real Com Port, TCP Server/Client, UDP Server/
Client, and Virtual Modem
Real COM driver for Windows 2000 or higher and Windows Server 2003/
2008
Real TTY driver for Linux
Fixed TTY driver for UNIX
Supports baud rates of 300, 600, 1200, 1800, 2400, 4800, 9600, 19200,
28800, 38400, 57600, 115200, 230400 bps
Language
Multi-language web-based GUI – available in English, German, Japanese,
Korean, Russian, Simplified Chinese and Traditional Chinese
Note: Fixed TTY Driver Supports 1) OpenServer (Sco Unix); 2) UnixWare 7,
SVR 5; 3) UnixWare 2.1, SVR 4.2; 4) QNX 4.25, QNX 6; 5) FreeBSD;
6) Solaris 10; 7) AIX 5.x; 8) HP-UX 11i.
