Aten SN0148CO [201/203] Account policy commands

Appendix

185

Account Policy Commands

acctp

Example:

acctp

Description:

Display the settings of the account policy.

acctp name <min_length>

Example:

acctp name 8

Description:

Set the minimum length of the username to at least a value of 8. The available

value of the parameter

<min_length> is from 1 to 32.

acctp pwd <min_length>

Example:

acctp pwd 8

Description:

Set the minimum length of password to at least a value of 8. The available value

of the parameter

<min_length> is from 1 to 32.

acctp pwdup <on/off>

Example:

acctp pwdup on

Description:

Require that the password must include at least one uppercase character.
