eco PDU Series User Manual
62
Specifications
PE6216A
Function PE6216A
Power Outlets Direct 16
Connectors Power Inlet 1 x IEC 60320 C20
Power
Outlets
NEMA 14 x NEMA 5-15R; 2 x NEMA 5-20R
IEC NA
Sensor 2 x RJ-11
LAN 1 x RJ-45 Female (Silver) + LEDs (Orange/Green)
LEDs Outlet Status 16 (Orange)
PDU Current / IP 2 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 1 x Non-fuse Breaker
Button 1 x Pushbutton
I/P Rating 100 – 120 V; 50 – 60 Hz; 16 A (UL), 20 A (Max.)
Power Capacity 2.4kW
O/P Rating Per Port NEMA 5-15R 100 – 120 V ; 50 – 60 Hz; 12 A (UL), 15 A (Max.)
NEMA 5-20R 100 – 120 V; 50 – 60 Hz; 16 A (UL), 20 A (Max.)
Total 100 – 120 V; 50 – 60 Hz; 16 A (UL), 20 A (Max.)
Environment Operating Temperature
0 – 50
o
C
Storage Temperature
-20 – 60
o
C
Humidity 0 – 80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 3.7 kg
Dimensions (L x W x H) 132.48 x 6.60 x 4.40 cm
