Chapter 1. Introduction
9
Note: Holes for ATEN Lok-U-Plug cable holders are located around the
outlets. See Securing the Cables, page 19, for further information.
No. Item Description
1 power inlet The power cord that connects the unit to an AC
power source plugs into this IEC 60320 C20
socket.
2 circuit breaker pushbutton As a safety measure, if there is an over current
situation regarding the device’s power, the circuit
breakers will trip. Press the button to recover
normal operation.
3 power outlets* 2 x NEMA 5-20R
14 x NEMA 5-15R
4 sensor ports External sensors plug into these two RJ-11 ports.
5 LAN port and LEDs The cable that connects the eco PDU to the LAN
plugs in here. The Link and LAN LEDs are built
into the LAN port:
Link: Lights GREEN to indicate that a connection
via the eco PDU's RJ-45 Ethernet port has been
established. Flashes to indicate data is being
transmitted.
LAN: Lights ORANGE to indicate 10 Mbps data
transmission speed. The LED lights GREEN to
indicate 100 Mbps data transmission speed.
6 readout section & reset
switch
Details of this section are provided on page 20.
7 outlet status LEDs These LEDs indicate outlet status.
Lights ORANGE for powered on.
Off for powered off.
