Appendix
63
PE6216B / PE6324B
Function PE6216B PE6324B
Power Outlets Direct 16 24
Connectors Power Inlet / Cord 1 x IEC 60320 C20 (inlet) 1 x NEMA L6-30P (cord)
Power
Outlets
NEMA NA
IEC 14 x IEC 60320 C13
2 x IEC 60320 C19
21 x IEC 60320 C13
3 x IEC 60320 C19
Sensor 2 x RJ-11
LAN 1 x RJ-45 Female (Silver) + LEDs (Orange/Green)
LEDs Outlet Status 16 (Orange) 24 (Orange)
PDU Current / IP 2 (Green)
Current / IP Address 3-digit 7-segment (Orange)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 1 x Non-fuse Breaker 2 x UL 489 Breaker
Button 1 x Pushbutton
I/P Rating 100 – 240 V; 50 – 60 Hz;
16 A (UL), 20 A (Max.)
100 – 240 V; 50 – 60 Hz;
24 A (UL), 30 A (Max.)
Power Capacity 4.2 kW 6.2 kW
O/P Rating Per Port IEC 60320
C13
100 – 240 V; 50 – 60 Hz;
12 A (UL), 15 A (Max.)
100 – 240 V; 50 – 60 Hz;
12 A (UL), 15 A (Max.)
IEC 60320
C19
100 – 240 V; 50 – 60 Hz;
16 A (UL), 20 A (Max.)
100 – 240 V; 50 – 60 Hz;
12 A (UL), 15 A (Max.)
Total 100 – 240 V; 50 – 60 Hz; 16
A (UL), 20 A (Max.)
100 – 240 V; 50 – 60 Hz;
24 A (UL), 30 A (Max.)
Environment Operating Temperature
0 – 50
o
C
Storage Temperature
-20 – 60
o
C
Humidity 0 – 80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 3.7 kg 6.3 kg
Dimensions (L x W x H) 132.48 x 6.60 x 4.40 cm 177.50 x 6.60 x 4.40 cm
